QP.G-400 shisha packing machine

This machine applies the transmission principle. It uses the slot wheel dividing system to drive the turntable to do intermittent movement. The machine has 8 sits. It can automatically put the tube inside the tube seat,fill the material into the tubes



Applications:

The machine for food, medicine, chemicals, hardware, agriculture, health care products, shisha tobacco and other items with viscous but bad flowing ability.

Like: prepared opium paste, Hookah cream, shisha, Arabia shisha, Turkish shisha, Arfak hookah, 50 gram small scale shisha, large scale shisha, fruit smell shisha.

Characteristic:

1. Micro-computer controller, big interface screen with high level of intellectual and automatic.
2. High precision of bag making by stepless adjustment of bag length. Easy for operation.
3. Thermocouple sampling adopted, digital conversion, Temperature compensation technology. It makes temperature stable and sealing more precisely.
4. Pneumatic module sealing technology adopted, which makes sealing edge neat and flat.
5. Adjustable air exhaust device adopted, which increase exhaust efficiency.
6. cellular machine structure, which makes it convenient to change spare parts.
7. New Horizontal Screw metering mechanic structures, which solves the high hardness of viscous paste material measurement problems
8. New horizontal mixing device adopted, better than vertical type.
9. Piston filling system, which make hard & high viscous materials fall smoothly into bag.

Technical parameters:

MODEL	QP.G-400	QP.G-400	QP.G-400	QP.G-400
Filling range （ml）	50g	100g	250g	500g
Bag size （mm）	L：70-150 W：60-80	L：80-200 W：60-180	L：80-200 W：60-180	L：120-200 W：180-260
Max speed （bag/min）	20-40	20-40	15-30	10-20
Power （kw）	2.0	2.0	2．5	2.5
Machine dimension （mm）	1040*600*2040	1400*700*2290	1400*700*2290	1550*780*2360
Machine weighet （kg）	300	300	350	400
